Analysis & Jobs
Run pipelines of plugin, slice, and expression stages on trajectories, and follow the execution model behind them.
An analysis is a persisted run of one plugin against a trajectory, stored with its trajectory context, status, progress, and result exposures. Analyses are never started on their own: they are stages of a pipeline run, submitted together from the Canvas and executed on the cluster runtime.
Pipelines, runs, and stages
executePipeline is the single entry point for analysis — the canvas uses it, and so does Volt AI through its execute_pipeline tool. One submission creates one pipeline run: an ordered, recorded chain of stages against a chosen set of timesteps.
Stages are ordered, and each one sees the dump the stages before it produced:
| Stage | Submitted as | Produces an analysis? | What it does |
|---|---|---|---|
| Analysis | plugin | Yes — one per stage | Runs a plugin workflow and writes result exposures |
| Slice Plane | slice | No | Cuts the structure with a plane, so later stages only see what survives |
| Expression Select | expression | No | Keeps or removes atoms by a property expression |
| Color Coding | not submitted | No | A local visual mapping — it changes what you see, never what the cluster computes |
Only plugin stages become analyses. Slice and expression stages leave no analysis behind, but they are still recorded on the run, because without them a result cannot explain how it was obtained.
An expression stage is stored negated relative to what you typed. The daemon keeps what the expression matches, while the UI asks what to remove, so x > 10 is submitted as !(x > 10). Restoring a run into the editor un-wraps it again — the round trip is lossless, but the stored form reads inverted if you inspect it directly.
Stage caching
Before planning a stage, the runtime hashes its configuration together with its inputs. On a hit, the stage is served from the analysis that already computed it and no new analysis is created — the run records which analysis it borrowed from.
This means two useful things and one surprising one:
- re-running an unchanged pipeline is close to free,
- changing stage 3 re-runs only stage 3 onward,
- and a run whose every stage was cached still appears in the sidebar, reporting that nothing was computed.
Following a run
The right sidebar of the canvas groups results by run, newest first, so a result sits underneath the chain that produced it rather than in a flat list. Within a run each row is one stage; the selectable leaf is still the exposure.
Grouping degrades rather than dropping rows:
- analyses from before pipeline runs existed, or whose run is outside the fetched page, collect in one trailing ungrouped section,
- a plugin stage whose analysis is off-page renders as a disabled row carrying the plugin name, so the chain never loses a link,
- and the public/shared canvas — which has no runs endpoint — simply shows everything ungrouped.
Listing
The analysis listing at Analysis Configurations is a history of executions, not a library of templates. Each row reports the plugin, the target trajectory, the progress, and the final state.
| Status | Meaning |
|---|---|
| Pending | The analysis exists, but workers have not started processing its frame work |
| Running | One or more frames are actively being processed |
| Completed | The full run finished successfully |
| Failed | Some frame work failed and can be retried selectively |
A run's own status is derived from its analyses rather than stored, so the two can never disagree.
Frame-based progress
Most analyses are frame-aware workloads. A run can represent many individual frame jobs, and the progress bar reflects that breakdown. A partially successful run is still useful: only the failed portion needs to be retried.
Two details are worth knowing when reading progress:
- Retrying counts as queued, not running. The attempt that failed has already ended, so a frame waiting on a retry is reported as queued.
- Artifact uploads are excluded from an analysis' own progress. "How far along is this analysis" and "is anything happening on this frame" are different questions, and upload work only answers the second.
Real-time updates arrive over the same event-driven layer used by the rest of VOLT.
Retrying failed frames
VOLT requeues only the failed frames for a given analysis, avoiding re-running already-completed frame work for heavier plugins.
Results, exposures, and exports
Completed analyses write results into cluster storage and project them into VOLT in several forms:
| Form | Description |
|---|---|
| Listings | Structured tabular views of the output |
| Sub-listings | Focused slices of a larger result |
| Charts | Visual summaries exported by the plugin |
| 3D artifacts | Overlays loaded back into the canvas scene |
These start as Apache Parquet files in the cluster's object store and are queried in place with DuckDB, so opening a listing does not require materializing the whole result.
Jobs layer
The Jobs system is the operational side of analysis, tracking work across the team with a dedicated view for queue activity, running jobs, and retries.
The hierarchy is:
- A trajectory-level group at the top.
- Frame-level groups within that trajectory.
- Individual per-frame jobs performing the processing.
The Jobs panel is team-wide, reporting queue activity across all workspace members in real time. On the cluster the work is spread across named queues — analysis_processing and pipeline_processing for computation, plus artifact_upload, plugin_warmup, and the trajectory queues — each drained by its own workers.
Team-wide job actions
The jobs interface exposes two maintenance actions per trajectory group: retrying failed work, and removing running jobs (which also clears queued and retrying jobs).
